Ethereal Glass

See Beyond the Screen

Redefining AR

  • Real Depth

    Prolonged use without visual conflict, eye-strain and nausea.

  • Prescription Compatibilty

    Tailor-made experience matching visual need.

  • Transparent Lenses

    Natural eye contact, without glow and reduced rainbow effect.

  • Highest Brightness At Low Power

    Enables a comfortable expereince in any environment.

  • Efficient Light Field Generation

    Allows low computing requirements.

  • Empower Developers

    Create immersive, intuitive experiences that enhance reality.

Specifications

Per Eye

Angular resolution (at infinity)

40 ppd

Modulator Resolution

1 Mpix (1:1 ratio)

Depth Resolution

Continuous

FoV (Diagonal)

36°

Effective Eyebox (exit pupil)

13 mm (6 mm)

Eye Relief

20 ± 3 mm

Modular Frame Rate

160 Hz

Sub-Frame Rate

6.5 kHz

Colors

2 millions

Brightness

2000 nits

Contrast

1000/1

Combiner Type

Holographic, Prescription Capable

Transparency

91%

Virtual Image Correction

Sphere, Cylinder Axis

Power Consumption

Light Source

8 mW @500 nits (+driver)

Modulator

90 mW (+driver)

*Pending CREAL License
